Welcome to the Tru-Bolt Electronic Lock Manual! This guide provides comprehensive instructions for installing, programming, and maintaining your electronic lock, ensuring optimal functionality and security.

1.1 Overview of the Tru-Bolt Electronic Lock System

The Tru-Bolt Electronic Lock System offers a secure and convenient keyless entry solution; Designed with an electronic deadbolt and keypad, it supports programmable master and user codes. The system includes alerts for low battery and tamper attempts, ensuring enhanced security. It is backed by a 1-Year Electronic Warranty and a Limited Lifetime Mechanical Warranty, providing durability and reliability for residential use.

1.2 Importance of Following the Manual

Following the manual ensures proper installation, programming, and maintenance of your Tru-Bolt Electronic Lock. It helps prevent errors, avoids voiding the warranty, and ensures optimal security. By adhering to the guidelines, you can troubleshoot common issues effectively, replace batteries correctly, and maintain the lock’s functionality for years to come.

Installation Guide for the Tru-Bolt Electronic Lock

Install your Tru-Bolt Electronic Lock securely by following step-by-step instructions. Ensure proper alignment of components and use the recommended tools for drilling and mounting the lock system.

2.1 Tools and Materials Required

To install the Tru-Bolt Electronic Lock, you will need a 1/16 drill bit, screws, a pencil, a tape measure, and a screwdriver. Additional tools include a chisel for door preparation and a 2-1/8” hole saw for drilling the lock face. Ensure all components are included in the package, such as the keypad, deadbolt, mounting plate, and strike plate. High-quality AA alkaline batteries are also required for operation.

2.2 Step-by-Step Installation Instructions

Begin by marking the center hole on the door edge using the template. Drill a 2-1/8” hole through the door face for the lock set. Chisel the area if necessary for proper fit. Assemble the exterior and interior components, ensuring the deadbolt aligns with the strike plate. Secure the mounting plate and strike plate. Connect the control wire and test functionality to confirm proper operation.

2.3 Common Installation Mistakes to Avoid

Avoid misaligning the latch bolt with the strike plate, as this can cause jamming. Ensure the door handing is correct before drilling. Do not overtighten screws, as this may damage the lock mechanism. Verify the backset measurement matches your door thickness. Properly route the control wire to prevent obstruction. Double-check all measurements before drilling to avoid costly repairs and ensure smooth operation.

Programming Instructions for the Tru-Bolt Electronic Lock

Master the programming process with easy-to-follow steps for setting codes, enabling features, and customizing your lock’s functionality to suit your security needs effectively.

3.1 Setting Up the Master Code

To set up the master code, enter the current master code, press the programming button, then input the new master code, and confirm by pressing the button again. This ensures secure access and allows you to customize the lock’s primary authorization code effectively.

3.2 Adding and Deleting User Codes

To add a user code, enter the master code, press the programming button, input the new user code, and confirm. To delete, enter the master code, press the button, and input the existing user code to remove. Ensure the lock has more than one code before deletion to maintain functionality and security.

3.3 Programming the Auto-Lock Feature

To enable the auto-lock feature, enter the master code and press the programming button. Use the keypad to set the desired delay (20-900 seconds). Confirm by pressing the programming button again. This feature ensures the lock automatically secures the door after the set time, enhancing convenience and security. The default setting is 30 seconds if not customized.

Troubleshooting Common Issues

Address common problems like battery depletion or latch misalignment by referencing diagnostic guides. Resetting the lock or realigning components often resolves issues quickly and effectively.

4.1 Resolving Battery-Related Problems

If the lock exhibits slow response or low battery alerts, ensure all connections are clean and secure. Replace batteries with high-quality alkaline ones, avoiding mixed or old cells. If issues persist, reset the lock following the manual’s instructions or refer to troubleshooting guides for advanced solutions to restore optimal functionality.

4.2 Fixing Jammed Latch or Misalignment Issues

Inspect the latch and strike plate for proper alignment. Ensure the door is evenly hung and the latch bolts smoothly. Clean debris from the latch area and lubricate if necessary. If misalignment persists, adjust the strike plate or consult a professional. Refer to the manual for detailed adjustment instructions to restore proper lock function.

4;3 Resetting the Lock to Factory Settings

To reset the Tru-Bolt lock to factory settings, press and hold the programming button for 10 seconds until the keypad flashes. Enter the master code, followed by the reset code (found in the manual). This will restore default settings, erasing all user codes and auto-lock configurations. Ensure all codes are backed up before proceeding with the reset process.

Maintenance and Care Tips

Regularly clean the keypad with a soft cloth and mild detergent. Lubricate the latch mechanism annually for smooth operation. Avoid harsh chemicals to prevent damage and ensure longevity.

5.1 Cleaning the Keypad and Lock Mechanism

Use a soft cloth and mild detergent to clean the keypad, avoiding harsh chemicals. Gently wipe away dirt and grime. For the lock mechanism, use compressed air to remove dust and debris. Regular cleaning ensures smooth operation and prevents wear. Avoid spraying cleaners directly on the lock to prevent damage to internal components. Inspect and clean periodically for optimal performance.

5.2 Replacing Batteries and Ensuring Proper Functionality

Replace the batteries with 4 high-quality AA alkaline batteries when the low-battery alert sounds or the lock malfunctions. Ensure the lock is powered off during replacement. Insert batteries correctly, matching the polarity indicators. Secure the battery compartment tightly to maintain functionality. Test the lock after replacement to confirm proper operation. Dispose of old batteries responsibly to protect the environment.

Warranty Information

The Tru-Bolt Electronic Lock is backed by a 1-Year Limited Warranty for electronic components and a Limited Lifetime Warranty for mechanical parts and finish durability.

6.1 Coverage and Duration of the Warranty

The Tru-Bolt Electronic Lock is covered by a 1-Year Limited Warranty for electronic components and a Limited Lifetime Warranty for mechanical parts and finish. This warranty protects against defects in materials and workmanship under normal residential use and is valid for the original purchaser only.

6.2 Conditions for Warranty Claims

Warranty claims require proof of purchase and must be made by the original residential user. Defects due to normal use are covered, but misuse, tampering, or non-residential use void the warranty. Proper installation following manual instructions is essential for coverage. Damage from external factors or improper handling is excluded.

Security Features of the Tru-Bolt Electronic Lock

The Tru-Bolt lock features advanced locking mechanisms, low-battery alerts, and tamper-detection systems, ensuring robust security for your home or office, with reliable access control.
